Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machines. They produce equipment such as boom lifts, aerial lifts and manlifts. These equipments are designed to facilitate access to difficult to reach places, buildings and roofs, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt only moves in one direction and contains steps or handholds or paltforms which are connected to the unit in order to transport workers from every floor.
TB85
The Terex TB85 provides a maximum working height of 91 feet. Moreover, the maximum height of the platform reaches 85 feet. This model's maximum width is 8 feet, 1 and 1/2 inches. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model offers a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal measuring 75 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the maximum height of the platform is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height reaches 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
